Automatic Hot Stamping Machine

AOER Automatic Hot Stamping and Die Cutting Integrated Machine combines hot stamping and die-cutting functionalities to enable multi-process integrated processing. This significantly enhances equipment utilization while reducing investment and floor space costs. This advanced solution is ideal for high-end packaging production in industries that demand precision and efficiency.

High-speed and stable output, supporting large-scale production requirements of 7,000-7,500 sheets per hour;
Precise stepping function ensures accurate and controllable positioning for each hot stamping and die-cutting operation;
Eight-zone independent temperature control system enables zone-specific constant temperature adjustment, achieving high efficiency and energy savings;
Electrical components and wiring comply with European and American safety standards, ensuring safety in global production environments;

AEM-800T Automatic Hot Stamping And Die Cutting Machine

Max. Sheet Size:820×620 mm

Max. Machine Speed:7000 S/H

Liner Plate Thickness:7mm or 5+2mm

AEM-1050T Automatic High Speed Hot Foil Stamping Machine

Max. Sheet Size:1050×750 mm

Max. Machine Speed:7500S/H

Liner Plate Thickness:7mm or 5+2mm

AEM-1080T Automatic Die Cutting and Hot Stamping Machine

Max. Sheet Size:1080×780 mm

Max. Machine Speed:7000S/H

Cutting Plate Thickness:7mm

AEM-800T Automatic Hot Stamping Machine

Max. Sheet Size:800×620 mm

Max. Machine Speed:7000S/H

Liner Plate Thickness:7mm or 5+2mm

AEM-1080T Automatic Foil Stamping Machine

Max. Sheet Size:1080×780 mm

Max. Machine Speed:7000S/H

Liner Plate Thickness:7mm or 5+2mm

AEMG-1300T/1500T/1650T Automatic Mid-Speed Hot Foil Stamping Machine And Die Cutting Machine

Max. Sheet Size:1670×1210 mm

Max. die-cutting Speed:5200S/H

Liner Plate Thickness:7mm or 5+2mm

AEMG-1650T Heavy Automatic Foil Stamping Machine

Max. Sheet Size:1670×1210 mm

Max. die-cutting Speed:5200S/H

Liner Plate Thickness:7mm or 5+2mm

Machine and advantages

Integrated Processing System

AOER Automatic Hot Stamping and Die Cutting Integrated Machine realizes the integration of hot stamping and die-cutting functions, increasing equipment utilization by 40% and reducing investment and floor space costs by 35%. Key advantages include: simultaneous hot stamping and die-cutting in a single process, high-speed output of up to 7,500 sheets/hour for the AEM-1050T model, perfectly suited for high-end packaging, cosmetic boxes, and luxury goods production lines, providing an efficient solution for precision packaging processing.

Pressure cutting force

Automatic hot stamping machines' key technical feature is pressure cutting force, determined mainly by flywheel torque. Models like AEM-1050T offer max die-cutting pressure of 300 tons, MWB series provides 250-400×10000N cutting pressure. The flywheel system ensures stable pressure output, enabling precision of ±0.1mm and efficiency up to 7500 S/H, suitable for thick materials and hard molds processing.

High quality sliding bearing

The high-quality sliding bearing is crucial for Automatic Hot Stamping Machine's precision, stability and lifespan. Made of cast copper alloy, it offers superior wear resistance and thermal conductivity, forming a natural oxide film for reduced friction. Its excellent shock absorption ensures stable operation with ±0.1mm hot stamping precision. The bearing achieves 72dB noise level (below 85dB standard) through friction reduction and vibration damping. With over 5-year lifespan (twice ordinary bearings), it reduces maintenance costs and extends equipment life, enhancing overall cost-effectiveness.

Functional diversification to meet the demand

Continuous technological research and development has brought about continuous innovation and enrichment of product functions, such as single-sheet die-cutting, continuous die-cutting and open delay functions, and the delay range can be adjusted at will, which can adapt to the requirements of different production processes.

Fully automatic feeding mechanism for leading edge feeders

Flyer feeder for large format die-cutting machines

View Technical Details

FAQ

When purchasing hot foil stamping equipment, what key performance parameters should be focused on to meet production needs?

Focus on the stamping precision, maximum stamping area, compatible foil type and production speed of hot foil stamping equipment to match your product size and capacity.

What preparations are needed before starting a newly purchased hot foil stamping equipment for the first time?

Check the circuit connections and stamping head flatness of hot foil stamping equipment, install compatible foil, adjust temperature and pressure, then start after confirming no abnormalities.

How to avoid blurry stamping when using hot foil stamping equipment daily?

Regularly clean the stamping head of hot foil stamping equipment, replace worn parts, and adjust the right temperature based on foil material to prevent too high or low temperature.

What checks are needed for hot foil stamping equipment to ensure safe operation after long-term idleness?

Check wire aging, grease condition of lubricated parts of hot foil stamping equipment, test the temperature control system, and ensure no safety hazards before use.
